| CPU | LGA1700 socket: Support for 12th/13th/14th Gen Intel® Core™, Pentium® Gold, Celeron®
L3 cache varies with CPU
(Please refer "CPU Support List") |
| Chipset | Intel® B760 Express Chipset |
| Memory | DDR4 5333–2133 MT/s (O.C.)
4 x DDR DIMM sockets, up to 128 GB (32 GB per DIMM)
Dual channel, ECC (non-ECC mode) & non-ECC support
XMP support (*CPU/memory config may affect compatibility; see "Memory Support List") |
| Onboard Graphics | Intel® HD Graphics
1 x DisplayPort 4096x2304@60Hz (DP1.2, HDCP2.3)
1 x HDMI 4096x2160@60Hz (HDMI2.1, HDCP2.3)
Support for up to 3 displays |
| Audio | Realtek® Audio CODEC, HD Audio, 2/4/5.1/7.1-channel
S/PDIF Out (*configurable via software) |
| LAN | Realtek® 2.5GbE LAN (2.5G/1G/100M) |
| Expansion Slots | CPU: 1 x PCIe x16 (PCIe4.0 x16)
Chipset: 1 x PCIe x16 (PCIe3.0 x4) |
| Storage Interface | CPU: 1 x M.2 (2280 PCIe4.0 x4/x2) (M2A_CPU)
Chipset: 1 x M.2 (22110/2280 PCIe4.0 x4/x2) (M2P_SB)
4 x SATA6Gb/s, RAID 0/1/5/10 support |
| USB | 1 x USB Type-C 3.2 Gen2 (internal)
5 x USB3.2 Gen1 (3 back, 2 internal)
1 x USB2.0/1.1 (back)
8 x USB2.0/1.1 (4 back, 4 internal) |
| Internal I/O Connectors | 1 x 24-pin ATX, 1 x 8-pin ATX12V
CPU fan header, 3 system fan headers
2 x addressable LED, 2 x RGB LED headers
2 x M.2 Socket 3, 4 x SATA6Gb/s
Front panel/audio/USB headers, TPM header, serial header
2 x Thunderbolt™ add-in connectors, Q-Flash Plus button, reset jumper, Clear CMOS
1 x USB Type-C header (USB3.2 Gen2), 1 x USB3.2 Gen1 header, 2 x USB2.0/1.1 headers |
| Back Panel Connectors | 3 x USB3.2 Gen1, 5 x USB2.0/1.1
1 x HDMI 2.0, 1 x DisplayPort, 1 x RJ-45
3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Water flow, Fan fail, Fan speed control (*depends on fan) |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP1.0a, DMI2.7, WfM2.0, SMBIOS2.7, ACPI5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus (*features may vary) |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX; 24.4cm x 24.4cm |
