| CPU | AMD Socket AM5, support for AMD Ryzen™ 9000/8000/7000 Series Processors. (Refer to GIGABYTE website for latest CPU support list.) |
| Chipset | AMD B850 |
| Memory | DDR5 8200(OC)/8000(OC)/7950(OC)/7900(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5200/4800/4400 MT/s. 4 x DDR5 DIMM up to 256 GB (64 GB per DIMM), dual channel. Non-ECC supported. AMD EXPO™ and XMP supported. |
| Onboard Graphics | AMD Radeon™ Graphics support. 1 x HDMI (4096x2160@60Hz, HDMI 2.1 & HDCP 2.3, HDR), 2 x DisplayPort (3840x2160@144Hz, DP 1.4). Up to triple-display support. Specifications vary by CPU. |
| Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel. Configurable via audio software. |
| LAN | Realtek® 2.5GbE LAN chip (2.5/1/0.1 Gbps) |
| Wireless | Realtek® Wi-Fi 6E RTL8852CE, 2.4/5/6 GHz, BLUETOOTH 5.3, 11ax 160MHz standard. Actual data rate may vary. |
| Expansion Slots | CPU: 1 x PCIe x16 (PCIe 5.0 x16 for Ryzen 9000/7000, PCIe 4.0 x8/x4 for 8000 Phoenix). Chipset: 1 x PCIe x16 (PCIe 3.0 x4) |
| Storage Interface | CPU: 2 x M.2 (M2A_CPU & M2B_CPU, PCIe 4/5 x4/x2). Chipset: 1 x M.2 (M2C_SB, PCIe 4.0 x2), 4 x SATA 6Gb/s. RAID 0/1/5/10 support (RAID5 only for Ryzen 9000 Series). |
| USB | CPU: 1 x USB Type-C (Gen2), 1 x USB 3.2 Gen2 Type-A (red), 4 x USB 2.0/1.1. Chipset: 1 x USB Type-C (Gen2), 4 x USB 3.2 Gen1 (2 back, 2 internal), 4 x USB 2.0/1.1 internal. |
| Internal I/O Connectors | 1 x 24-pin ATX, 1 x 8-pin ATX 12V, CPU/system fan headers, 4 x SATA 6Gb/s, 2 x M.2, RGB and addressable LED headers, USB Type-C header, USB 3.2 Gen1 header, TPM header, reset/clear CMOS/Q-Flash Plus buttons. |
| Back Panel Connectors | 1 x HDMI, 2 x DisplayPort, 1 x PS/2, 1 x USB Type-C (Gen2), 2 x USB 3.2 Gen1, 1 x USB 3.2 Gen2 Type-A (red), 4 x USB 2.0/1.1, 1 x RJ-45, 2 x antenna connectors, 3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Water cooling flow, Fan fail warning, Fan speed control (*depends on installed fan/pump) |
| BIOS | 1 x 256 Mbit flash, Licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX; 24.4cm x 24.4cm |
